Description
A centrifugal lobe pump is a positive displacement pump that transfers fluid by means of the rotary motion of two lobes. It is designed for handling delicate, shear-sensitive fluids, and is often used in industries such as food, pharmaceutical, and biotechnology where hygiene is essential. The pump’s gentle pumping action makes it ideal for processing viscous fluids and solids without causing damage to the product.
Key Features
- Gentle Pumping: Ensures product integrity, especially for shear-sensitive fluids.
- High Efficiency: Capable of handling highly viscous materials without significant loss of efficiency.
- Hygienic Design: Ideal for industries requiring high levels of cleanliness, such as pharmaceuticals and food.
- Easy Maintenance: Designed with quick disassembly for easy cleaning and maintenance.
Applications
- Food and Beverage: Transporting products such as creams, sauces, and beverages.
- Pharmaceutical: For transferring pharmaceutical products without compromising product quality.
- Biotechnology: Used in biotech processes for fluid handling with minimal degradation.
- Cosmetics: Handles lotions, creams, and gels with delicate care.
- Dairy Industry: Milk, cream, and yogurt processing.
Technical Specifications
| Parameter | Details |
|---|---|
| Type | Centrifugal Lobe Pump (Positive Displacement) |
| Material Construction |
- Casing: Stainless Steel - Lobes: Stainless Steel or Rubber-Coated - Seals: Carbon/ceramic, Silicon Carbide |
| Flow Rate (Capacity) | 5 to 100 m³/h (varies by model) |
| Max Pressure | Up to 15 bar |
| Viscosity Range | 1 cP to 100,000 cP |
| Discharge Size | 1 inch to 6 inches |
| Motor Power | 0.75 kW to 30 kW |
| Temperature Range | -20°C to +150°C |
| Pump Orientation | Horizontal |
| Typical Applications |
- Food and Beverage - Pharmaceuticals - Biotechnology - Cosmetics - Dairy Industry |
